Structural features:

QT4-26 type block forming machine is made up of machine frame, elevating system, vibrating system, mold , material storing device, delivering device and electronic controlling part.




Main technological parameters:

Molding pieces:390mm×190mm×190mm      4 pcs/mold
390mm×240mm×190mm      3 pcs/mold
390mm×120mm×190mm      6 pcs/mold
240mm×115mm×53mm       21 pcs/mold
(Note: different specification mold  can be made accordingly)
Molding cycle: 26s
Vibration frequency: 2800-4200r/min
Productivity: 3000-4000 pcs/day (8 hours)
Host machine power: 11.25kw
Excitation force: 45KN
Molding type: platform vibration
Pallet size: 850mm×450mm×40mm
Overall dimension: 3600mm×1700mm×2560mm (working state)
Weight: 1750kg


Foundation work for the machine:



Finished Blocks Show:
