Qt12 -15 Automatic Brick Machine Cement Brick Machine Red Brick Machine

1. QT12-15 Automatic block machine production capacityNoSize(LxWxH)Pcs/MouldPcs/HourPcs/Shift1400x200x200mm121800-216014400-172802400x100x200mm243300-396026400-316803400x150x200mm162100-252016800-201604400x110x70mm507500600005200x100x60mm 426300504006200x163x60mm 24370029600 2. QT12-15 forming technical parameters

Featured Products

Qt12-15 Automatic Brick Block Machine Cement Brick Making Machine Red Brick Making Machine

1
. QT12-15 Automatic block machine production capacity

No

Size(LxWxH)

Pcs/Mould

Pcs/Hour

Pcs/Shift

1

400x200x200mm

12

1800-2160

14400-17280

2

400x100x200mm

24

3300-3960

26400-31680

3

400x150x200mm

16

2100-2520

16800-20160

4

400x110x70mm

50

7500

60000

5200x100x60mm

42630050400
6200x163x60mm

24370029600

Qt12-15 Automatic Brick Block Machine Cement Brick Making Machine Red Brick Making Machine

Qt12-15 Automatic Brick Block Machine Cement Brick Making Machine Red Brick Making Machine

Qt12-15 Automatic Brick Block Machine Cement Brick Making Machine Red Brick Making Machine



2. QT12-15 forming technical parameters


1.Dimension of host machine

3800×2300×2900mm

6.Host machine power

44kw

2.Weight of host machine

11t

7.Vibration force

100KN

3.Moulding area

1220*880

8.Mixer model

JS750

4.water consumption

12-15t/day

9.Pallet size

1300*900*28mm

5.workshop area

300m2

10.Voltage

380/415/440V



3.JS750 mixer


ModelJS750
Discharging capacity(L)750L
Charging capacity(L)1200L
Theoretical productivity(m3/h)35
Max. sizes of aggregate(mm)≤80
Cycle time(s)60
Hopper speed( m/min)18
Agitating vanerotate speed (r/min)31
quantity2×7
Mixer motormodelY180M-4
power(kw)30
Hoist motormodelYEZ132S-4
power(kw)7.5
Pump motormodelBL12-16-1.1
power(kw)1.1
Dimension(mm)traval status3110×2620×2580
(length x width x height)work status5025×3100×5680
Weight(kg)5500


4.Belt conveyor:


Item



Specifaction

Length

6000mm

Width

500mm

Speed (m/min)

1.25 m/min

Specification (ton/hour)

30-40 ton/hour

power(kw)

1.1kw




Qt12-15 Automatic Brick Block Machine Cement Brick Making Machine Red Brick Making Machine
